TECHNICAL SPECIFICATIONS:

• Description: Innovative design, highly versatile with the latest gem optical high-quality coated lenses

• Magnification Changer: 3 Step (5x,10x & 20x) OR 5 Steps (4.0x, 6.0x, 10.0x, 16.0x & 25.0x)

• Binocular Tubes: 0 - 180 degree ergonomic head / 45 degrees inclined

• Eyepiece: 12.5x W.F/16mm Diopter Adjustment ± 6mm

• Optional:   15x W.F/16mm

• Working distance: F-250mm fine focus objective lens

• Optional: Objective lens 300 mm & 400 mm

• Interpupillary distance adjustment: 55 mm to 75 mm

• Focusing System: Manual through knob / Motorized with foot control

ILLUMINATION SECTION:

• Light Source: 200 Watt bright white led light up to 60,000 hours LED life with 100,000k lux

• Illumination Control: Continuous Adjustment

• Field of illumination: 70 mm

• Built-in-Filter: Green and Orange

STAND SECTION:

• Type: floor stand on four castor wheel with lock for easier handling and absolute stability

• Adjustment: Vertical height adjustment range of counter balanced pantograph

• Arm: 300 to 560 mm

• Rotation of arm: 320 with lock

CONTAINS ALL ACCESSORIES:

• Digital High-Definition  Camera  Imaging System

• Beam Splitter with 'C' Mount and Camera

• LED Screen 24" for live surgery

• Mobile Adaptor Floor Stand for live surgery

•  Motorized fine focusing  with foot control.
